Current & Voltage (3 Tiers)
Standard Circular Connectors: ≤24A / 450V (Exception: HYTYM25 series: 32A / 250V)
Current & Voltage (3 Tiers)
Basic Square Junction Boxes: 16A / 450V
Current & Voltage (3 Tiers)
High-Current Custom Boxes: 40A / 450V (Sub-series HTX686-5-707: up to 57A / 450V)
Operating Temperature Ranges
Standard Circular Connectors: -40°C ~ +95°C
Operating Temperature Ranges
HYTM12/16 & Square Boxes: -40°C ~ +105°C
Operating Temperature Ranges
High-Current Boxes (826/457/708/709 series): -40°C ~ +110°C
Operating Temperature Ranges
707 Series: -40°C ~ +110°C
Ingress Protection (IP) Ratings
General Rule: Nearly all waterproof connectors, square boxes, and custom high-current boxes: IP68
Ingress Protection (IP) Ratings
Key Exception: HTX686-5-707 series is rated IP66 (Note this distinction during selection)
Ingress Protection (IP) Ratings
Terminal Blocks & Splitters (HPCT / HS / HCY): No IP rating; intended for indoor DIN-rail mounting.
